MAEDA 264
Mini tap from VACSER is a useful little strongman! Regardless of its compact size, it is designed to be installed in highly accessible locations. Its maneuverability and weight allow you to easily cope with obstacles where big cars simply cannot pass. If you need to lift something in a narrow space or in a small area, this faucet will become your best friend!
Load capacity: <2500 kg
Line length: 6.9 m
9 000 грн.
- with VAT per change
 |
GLASS |
 |
SANDWICH PANEL |
 |
STONE |
 |
| METAL |
 |
6,9 m |
 |
Max 2.5 t |
 |
GW 1.47 t |
TECHNICAL TABLE
Max. load capacity: 2500 kg.
Own weight: 1470 kg.
Max. boom reach: 6900 mm.
Max. radius: 5600 mm.
Ground pressure: 38.22Kpa (0.39kg / cm2)
Lifting angle: 20 °
Engine: Kawasaki FG300G Petrol
MAEDA 264 ADVANTAGES
Low ground pressure
Weighing just 1470 kg, our Maeda model is ideal for working in confined spaces. It provides low ground pressure and overlap, which is essential for preserving your site.
Compactness is what makes our mini crane a true hero in tight spaces! It can easily fit through single-leaf doors, so you don’t have to worry about limited space. Thanks to its small dimensions, you can work where other cranes simply can’t fit.
Powerful, regardless of its size, it can lift up to 2.5 tons, making it the perfect companion for any construction project.
