AERO-INDEPEND
Basic vacuum gripper with independent livestock and battery for greater rigidity within the workshop
Vantage capacity: <1000 kg
Positioning: horizontal
 |
| METAL |
 |
SANDWICH PANEL |
 |
GLASS |
 |
 |
TECHNICAL TABLE
Capacity: from 150 to 1000 kg. *
Positioning: horizontal
Number of suction cups: 4 to 8 pcs. *
Suction cup diameter: 170 to 270 mm *
Main traverse: length 2000 to 3000 mm *
Cross beam: 1000 mm
Vacuum pump: 4 m³/h.
Voltage: supplied by battery
* stay under the model
AERO-INDEPEND ADVANTAGES
It uses a battery that is guaranteed to have excellent battery life and short charging cycles. The battery level can be continuously charged using the additional battery indicator.
The maximum operating hour from the battery is due to the built-in pump module, which ensures intelligent regulation of the vacuum generator. (The pump switches to the cleaning mode as soon as the working vacuum is created).
The safety of the operator is guaranteed thanks to the large vacuum tank with an intelligent alarm device.
The vacuum level is displayed in real time using LED indicators, which provide information about the readiness of the system before operation.
Maximum reliability of the welding process of the steel structure frame and cross members.
The versatility of the modular base system has not been fully developed and can be individually expanded with additional options.
A short set-up time for different sizes of transport goods including suction cups that can be firmly fixed using manual clamps (already included in the basic kit).
Easy to maintain: the intelligent suction cup concept allows you to replace worn suction cups in seconds, practically without tools.
Safe and efficient transportation of high-viscosity surfaces with elastomer reinforcements with extremely sensitive terms of service
