CLAD-BOY
Original! Proven method for horizontal and vertical installation of sandwich panels, trapezoidal sheets, fire protection and wall elements.
Load capacity: <500 kg
Positioning: vertical, horizontal
 |
SANDWICH PANEL |
 |
| METAL |
 |
 |
 |
 |
TECHNICAL TABLE
Load capacity: from 240 to 500 kg. *
Panel length: up to 18000 mm *
Positioning: vertically, horizontally
Number of suction cups: from 6 to 16 pcs. *
Suction cup size: 80x400 / 36x780 mm *
Main crossbar: from 1000 to 8000 mm *
Transverse crossbars: 1000 mm
Vacuum pump: 4 m³ / h.
Power supply: battery **
* depends on the configuration
** built-in charger voltage 220 V
CLAD-BOY ADVANTAGES
Covers all tasks on the construction site thanks to universal suction cups that can handle all types of sandwich elements and trapezoidal sheets for facades and roofs.
CLAD-BOY – the original! Specially developed for use on construction sites: CLAD-BOY is completely weatherproof, extremely impact-resistant and also impresses with its low unladen weight.
Versatile and robust, suitable for both roof and wall mounting
Long-lasting operation and short charging times thanks to intelligent vacuum generator control
Maximum versatility and tool-free conversion thanks to modular and pluggable, hot-dip galvanized main and cross beams
Highest safety standards thanks to audible and visual warning of low battery and/or falling vacuum level
Up to 70% longer battery life thanks to the standard Ecomatic pump control module, which provides intelligent activity control measured by the vacuum level.
70-80% longer service life than conventional products thanks to the time-tested, quick-change and UV-resistant suction cups.
Convenient transport and storage options for all attachments and vacuum lifter thanks to the specially designed STORE-BOY XL storage unit, which also includes an equipment box for storing all tube or suction cup components.
