AERO-180°
Smooth, jerk-free rotation of transported loads from 0° to 180°.
Load capacity: <250 kg
Positioning: 180°
 |
| METAL |
 |
SANDWICH PANEL |
 |
GLASS |
 |
| SOLAR PANEL |
 |
TECHNICAL TABLE
Load capacity: from 150 to 250 kg. *
Positioning: horizontal
Number of suction cups: from 4 to 8 pcs. *
Suction cup diameter: from 170 to 270 mm *
Main traverse: from 2000 to 3000 mm *
Transverse traverses: 1000 mm
Vacuum pump: 4 m³ / h.
Voltage: 400 V **
* depends on the model
** possible conversion to 220 V
AERO-180° ADVANTAGES
Safe and gentle transport thanks to high-quality, fully elastomeric seals with an extremely long service life.
Unrivalled versatility of the modular basic system, which can be individually expanded with additional options.
No downtime thanks to the integrated motor protection switch that protects the vacuum generator against winding damage.
Guaranteed operational and operator safety thanks to the large vacuum tank with intelligent warning device.
Maximum process reliability thanks to the robust welded steel frame and crossbar construction.
Smooth and stepless rotation/swivel from 0° to 180° thanks to the electric rotary drive.
Low operating costs thanks to the energy-efficient vacuum generator and the additional pump control module, which perfectly regulates the operation of the vacuum generator.
Fast and easy maintenance: the intelligent suction cup concept allows worn suction cups to be replaced in seconds, practically without tools.
Short adjustment times for different transport sizes thanks to suction cups that can be individually locked using manual flaps (already included in the basic package).
GALLERY
